Commander SK Getting Started Guide 25
Issue Number: 1 www.controltechniques.com
Safety
Information
Rating
Data
Mechanical
Installation
Electrical
Installation
Keypad and
Display
Parameters
Quick Start
Commissioning
Diagnostics Options
Parameter
List
UL Listing
Information
L1: Level 1 access - only the first 10 parameters can be accessed
L2: Level 2 access - All parameters from 01 to 60 can be accessed
L3: Level 3 access - All parameters from 01 to 95 can be accessed
Loc: Used to lock a security code in the drive. See section 5.6 Security codes on
page 18 for further details.
6.2 Parameter descriptions - Level 2
diS: Mechanical brake software disabled
rEL: Mechanical brake software enabled. Brake control via relay T5 & T6. The digital
output on terminal B3 is automatically programmed as a drive healthy output.
d IO: Mechanical brake software enabled. Brake control via digital output B3. The relay
output on terminals T5 and T6 are automatically programmed as a drive healthy
output.
USEr:Mechanical brake software enabled. Brake control to be programmed by user.
The relay and digital output are not programmed. The user should programme the
brake control to either the digital output or relay. The output not programmed to
the brake control can be programmed to indicate the required signal. (See
Commander SK Advanced User Guide.)
See Pr 46 to Pr 51 on page 31.
No Function Range Defaults Type
10 Parameter access L1, L2, L3, Loc L1 RW
No Function Range Defaults Type
11 Start/Stop logic select 0 to 6 EUR: 0, USA: 4 RW
Pr 11 Terminal B4 Terminal B5 Terminal B6 Latching
0 Enable Run Forward Run Reverse No
1 Not Stop Run Forward Run Reverse Yes
2 Enable Run Forward / Reverse No
3 Not Stop Run Forward / Reverse Yes
4 Not Stop Run Jog Yes
5 User programmable Run Forward Run Reverse No
6 User Programmable User Programmable User Programmable User Programmable
A change to Pr 11 is set by pressing the MODE key on exit from parameter edit mode.
The drive must be disabled, stopped or tripped for a change to take place. If Pr 11 is
changed while the drive is running, when the MODE key is pressed on exit from
parameter edit mode, Pr 11 will change back to its previous value.
NOTE
M
M
No Function Range Defaults Type
12 Brake enable diS, rEL, d IO, USEr diS RW
A change to Pr 12 is set by pressing the MODE key on exit from parameter edit mode.
The drive must be disabled, stopped or tripped for a change to take place. If Pr 12 is
changed while the drive is running, when the MODE key is pressed on exit from
parameter edit mode, Pr 12 will change back to its previous value.
NOTE
M
M
Great care should be taken when implementing a brake control set-up, as this may cause
a safety issue depending on the application, e.g. crane. If in doubt, contact the supplier
of the drive for further information.
WARNING
