Control Techniques Epsilon EP-I

137
Options and Accessories
Epsilon EP Drive Options
Epsilon EP
reset
3 MIN
serial (J2)
L1
L2
PE
S
R
T
+
_
logic motor
digital i/o (J3)
J8
J6
J5
J10
EP204-I00-0000
9606XX-XX A1
SN 0610E014
Epsilon EP I/O Cable,
EIO26-xxx
Motor Feedback Cable, SIBAAA-xxx
STI-24IO
+24V
0V
1
2
3
4
5
6
7
8
OUTPUTS
1
2
3
4
5
6
7
8
INPUTS
9
10
11
12
13
14
15
EN
Windows 98, NT 4.0, 2000 or XP
Compatible Computer
(Customer Supplied)
CT-MME-POWER-CD
Contains PowerTools Pro
PC to Drive, PC RS232 to Drive RS485
Serial Interface Cable, CT-COMMS
ESA HMI to Drive,
ESA-SP-485-xxx
Drive to Drive,
Drive RS485 to Drive RS485
DDC-RJ45-xxx
Drive Sync Out to
Drive Sync In Cable,
SNCDD-915-xxx
Drive Sync Out Cable,
SNCFLOA-xxx
Drive Sync Out to
FM-3/4 Module In Cable,
SNCMD-815-xxx
Drive Sync In to Drive Sync Out Cable,
SNCDD-915-xxx
Drive Sync In Cable,
SNCFLI-xxx
Drive Sync In from
FM-3/4 Module Out Cable,
SNCMD-89-xxx
Motor Power Cable,
PSBAFA-xxx, PBBAFA-xxx
EZ Motors
Motor Power Cable,
CMDS-xxx or CMMS-xxx*
Motor Brake Cable,
CBMS-xxx*
NT or MG Motors
Motor Power Cable,
XCMDS-xxx or XCMDBS-XXX
Motor Brake Cable, XTBMS-xxx
Motor Power Cable, XTMDS-xxx
External Shunt Resistor,
SM-Heatsink DBR1
XV Motors
Motor Feedback Cable, XEFCS-XXX
Motor Feedback Cable, XEFTS-XXX
XV Motors
Motor Feedback Cable, EFCS-XXX*
NT or MG Motors
EZ Motors
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15
Drive Sync Out Breakout Board,
STI-SNCOA
Drive Sync In Breakout Board,
STI-SNCI
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15
Motor Feedback Breakout Board,
STI-ENC
1 2 3 4
5 6 7 8
Drive Brake Relay,
BRM-1
* Flex duty versions of these cables
are also available.
Epsilon EP-I Indexing Drive and FM-2 Indexing Module
Reference Manual
