Epsilon EP-I Indexing Drive and FM-2 Indexing Module Reference Manual
Module is setup using PowerTools Pro v4.0 software. PowerTools Pro v4.0 is an easy-to-use Microsoft® Windows® based
setup and diagnostics tool.
Figure 2: FM-2 Indexing Module Feature Location
Locking Latch
Aligning Tabs
100-Pin Connector
Front Back
1
2
3
4
5
6
7
8
1
2
3
4
+
-
Indexing Module
Inputs
Outputs
10-30 VDC
Inputs
Outputs
10-30 VDC
MODEL FM-2
PART 960503-01
REV EB/09
SER 9820B025
