M’Ax Advanced User Guide 54
Issue Number: 4 www.controltechniques.com
Parameter not used
Parameter not used.
This invert parameter is used to change the sense of terminal 5 on the Digital I/O port.
0 = Not inverted
1=Inverted
This invert parameter is used to change the sense of terminal 4 on the Digital I/O port.
0 = Not inverted
1=Inverted
This invert parameter is used to change the sense of terminal 3 on the Digital I/O port.
0 = Not inverted
1=Inverted
This invert parameter is used to change the sense of terminal 2 on the Digital I/O port.
0 = Not inverted
1=Inverted
This invert parameter is used to change the sense of terminal 8 and 10 on the MC/EIA485 port. Setting this parameter to a 1 causes the
output from the source parameter to be inverted.
0 = Not inverted
1=Inverted
This parameter should be programmed with the source parameter for terminal 5 on the Digital I/O port. Only bit parameters can be
programmed into this parameter. If a non-valid parameter is programmed an output will assume the last valid state (i.e. the value of previously
programmed parameter). After modification of this parameter the source is only changed when a reset is performed or a power down and
back up again. Defaulted to drive running.
This parameter should be programmed with the source parameter for terminal 4 on the Digital I/O port. Only bit parameters can be
programmed into this parameter. If a non-valid parameter is programmed an output will drive current. After modification of this parameter the
source is only changed when a reset is performed or a power down and back up again. Defaulted to At zero speed.
8.59 Status line indicator
ô
0~1
ð
RO Bit
8.60 Status line output enable
ô 0~1 ð RO Bit
8.61 Digital output 1 invert
ô
0~1
ð
0 RW Bit
8.62 Digital output 2 invert
ô 0~1 ð 0 RW Bit
8.63 Digital output 3 invert
ô
0~1
ð
0 RW Bit
8.64 Digital output 4 invert
ô
0~1
ð
0 RW Bit
8.65 Status relay invert
ô
0~1
ð
0 RW Bit
8.71 Digital output 1 source selector (DRIVE RUNNING)
ô 0.00 ~ 20.50 ð 10.02 Menu.Par RW Uni P
8.72 Digital output 2 source selector (AT ZERO SPEED)
ô
0.00 ~ 20.50
ð
10.03 Menu.Par RW Uni P
