Control Techniques M'Ax User Manual

*
55 M’Ax Advanced User Guide
www.controltechniques.com Issue Number: 4
This parameter should be programmed with the source parameter for terminal 3 on the Digital I/O port. Only bit parameters can be
programmed into this parameter. If a non-valid parameter is programmed an output will drive current. After modification of this parameter the
source is only changed when a reset is performed or a power down and back up again. Defaulted to Alarm indicator.
This parameter should be programmed with the source parameter for terminal 2 on the Digital I/O port. Only bit parameters can be
programmed into this parameter. If a non-valid parameter is programmed an output will drive current. After modification of this parameter the
source is only changed when a reset is performed or a power down and back up again. Defaulted to At speed.
This parameter should be programmed with the source parameter for the status relay on terminal 8 and 10 on the MC/EIA485 connector. Only
bit parameters can be programmed into this parameter. If a non-valid parameter is programmed the output will be open. After modifications of
these parameters the destinations are only changed when a reset is performed or the drive is powered down and back up again. Defaulted to
drive healthy.
8.73 Digital output 3 source selector (ALARM)
ô
0.00 ~ 20.50
ð
10.19 Menu.Par RW Uni P
8.74 Digital output 4 source selector (AT SPEED)
ô
0.00 ~ 20.50
ð
10.06 Menu.Par RW Uni P
8.75 Status relay source selector (DRIVE HEALTHY)
ô
0.00 ~ 20.50
ð
10.06 Menu.Par RW Uni P
