6.2 Single line descriptions
Parameter
Range(
Ú) Default(Ö)
Type
OL CL OL VT SV
x.01 Solutions Module ID 0 to 599 101 RO Uni PT US
x.02 No function
x.03 Speed feedback ±40,000.0 rpm RO Bi FI NC PT
x.04 Revolution counter 0 to 65,535 revolutions
RO Uni FI NC PT
x.05 Position
0 to 65,535 (1/2
16
ths of a
revolution)
RO Uni FI NC PT
x.06 No function
x.07 No function
x.08 No function
x.09 No function
x.10
Equivalent lines per
revolution
0 to 50,000 4,096 RW Uni US
x.11 No function
x.12 No function
x.13 Resolver excitation 3:1 (0), 2:1 (1 or 2) 3:1 (0) RW Uni US
x.14 No function
x.15 Resolver poles
2POLE (0), 4POLE (1),
6POLE (2),
8POLE (3 to 11)
2POLE (0) RW Uni US
x.16 No function
x.17 Error detection level 0 to 7 1 RW Uni US
x.18 No function
x.19 Feedback filter 0 to 5 (0 to 16 ms) 0 RW Uni US
x.20 No function
x.21 No function
x.22 No function
x.23 No function
x.24 Encoder simulation source Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni PT US
x.25
Encoder simulation ratio
numerator
0.0000 to 3.0000 1.0000 RW Uni US
x.26 No function
x.27 No function
x.28 No function
x.29
Non-marker reset
revolution counter
0 to 65,535 revolutions RO Uni NC PT
x.30 Non-marker reset position
0 to 65,535 (1/2
16
ths of a
revolution)
RO Uni NC PT
x.31 No function
x.32 No function
x.33 No function
x.34 No function
x.35 No function
x.36 Freeze position
0 to 65,535 (1/2
16
ths of a
revolution)
RO Uni NC PT
x.37 No function
x.38 No function
x.39 Freeze flag OFF (0) or On (1) OFF (0) RW Bit NC
x.40 No function
x.41 No function
x.42 No function
x.43 No function
x.44 No function
