8Terminal data
1
Simulated encoder output channel A
2
Simulated encoder output channel A\
Type EIA485 differential voltage
Maximum frequency 500kHz
Absolute maximum applied voltage relative to
0V
±14V
Protection Current limit with thermal protection
3
0V
Total current for all 0V terminals of Solutions
Module
200mA
4
Simulated encoder output channel B
5
Simulated encoder output channel B\
Type EIA485 differential voltage
Maximum frequency 500kHz
Absolute maximum applied voltage relative to
0V
±14V
Protection Current limit with thermal protection
6
0V
Total current for all 0V terminals of Solutions
Module
200mA
7
Simulated encoder output channel Z
8
Simulated encoder output channel Z\
Type EIA485 differential voltage
Maximum frequency 500kHz
Absolute maximum applied voltage relative to
0V
±14V
Minimum marker pulse width 300ns
Protection Current limit with thermal protection
