CONZERV DigitAN EM6400 User Manual

EM 6400 User Manual v03.02. – d12
19
DIAG
D1
D7
PROG
SET
R.Wh
REV
R.VAh
R.VAR
-R.VAR
R.run
t.Wh
TOT
t.VAh
t.VAR
-t.VAR
t.run
ON.h
INTR
Wh
OLD
VAh
VARh
-VARh
R.Wh
O.REV
R.VAh
R.VAR
-R.VAR
t.Wh
O.TOT
t.VAh
t.VAR
-t.VAR
VLL
A
PF
CLR
-VARh = -ve VAR hours, capacitive
Run.h = Run hours, Total hours the load was
ON, accumulates when the load current is
REV = Reverse energy (energy export)
R.VAh = Volt-ampere hours (export)
R.Wh = Watt hours (export)
R.VAR = VAR hours, inductive (export)
-R.VAR = -ve VAR hours, capacitive (export)
R.Run = Run hours, Total hours the meter was
running with reverse enrgy flow (export)
TOT = Total (import + export)
t.VAh = Total Volt – ampere hours (Import +
Export)
t.Wh = Total Watt-hours (Import + Export)
t.VAR = Total VAR-hours, Inductive (Import +
Export)
-t.VAR = Total Negative VAR-hours, Capacitive
t.run = Run hours, Total hours the meter was
running with reverse enrgy flow (export)
ON.h = ON hours. Total hours the meter was
ON. Accumulates if auxiliary supply is present
(irrespective of input signals).
INTR = Auxiliary interruption. Accumulates
the auxiliary interrupt
VAh = Old Volt – ampere hours (Import)
Wh = Old Watt-hours (Import)
VARh = Old VAR-hours, Inductive (Import)
-VARh = Old Negative VAR-hours, Capacitive
O.REV = Old reverse energy (Export)
R.VAh = Old Volt – ampere hours (Export)
R.Wh = Old Watt-hours (Export)
R.VAR = Old VAR-hours, Inductive (Export)
-R.VAR = Old Negative VAR-hours, Capacitive
(Export)
O.TOT = Old total energy (Import + Export)
t.VAh = Total Old Volt – ampere hours (Import
+ Export)
t.Wh = Total Old Watt-hours (Import + Export)
t.VAR = Total Old VAR-hours, Inductive
(Import + Export)
-t.VAR = Total Old Negative VAR-hours,
DIAG = Represents diagnostic pages. The values
contained in these pages are for factory testing
OLD = The energy values stored in the integrator
will be transferred to OLD register when the
Integrator is cleared (manually or due to overflow)
CLR = Clears the INTG values
1

CONZERV DigitAN EM6400 Specifications

General

Display	LCD
Operating Temperature	-10°C to +55°C
Storage Temperature	-25°C to +70°C
Communication	RS485
Measurement Parameters	Voltage, Current, Power, Energy, Power Factor, Frequency
Humidity	95% RH (non-condensing)
Input Current	5A
Accuracy	Class 0.5S (IEC 62053-22)
Current Range	1A or 5A (configurable)
