StreamEnjin User Manual
26
4 Media Select the source(s) and how the source(s) are laid out for
the scene.
1. Full Screen Mode
2. Select the source of the 1080p video input port (HDMI A
or B)
3. Dual View Mode (Picture-in-Picture or Picture-by-
Picture)
4. Plain Background
5 Add Text
Overlay
Tap this icon to add a text overlay. Refer to Add/Edit Text
Overlay on page 29 below for more information.
To edit the location and size of the overlay, select the
overlay in the “Overlay” region and configure in the “Scene
Display” region.
The added overlay will appear in the “Overlay” region.
Up to 30 text overlays (layers) are support per scene.
6 Add Image
O
verlay
Tap this icon to add an image overlay.
Tapping allows you to add an Image Overlay. iPad will
flip to the Photos page for you to select an image. Select
the image and tap OK.
To relocate, tap and hold the overlay to drag.
To resize, refer to Resize/Crop Tool on page 27.
The added overlay will appear in the “Overlay” region.
Up to 5 image overlays (layers) are support per scene.
7 Switch Video
Source (Dual-
View)
During dual-view, tapping this button switches video source
position between 1 and 2.
8 Scene
Information
This region displays the scene name and background.
Tap the field to edit.
9 Dual-View
Layout
Tap to select the preferred dual-view (Picture-in-Picture or
Picture-by-Picture) layout.
You can also resize the dual-view.
10 Apply Tap this button to apply the configuration into this scene.
11 Cancel Tap this button to cancel all configurations made in this
page.
No. Component Description
