6
General up counter (16bit)
C0～C15
16
points
0～32,767 counter
EEPROM hold up counter
(16 bit)
C16～C199
184
points
0～32,767counter
General bi-direction (32 bit)
C200～C219
20
points
-2,147,483,648～+2,147,483,647
counter
EEPROM hold bi-direction
(32 bit)
C220～C234
15
points
-2,147,483,648～+2,147,483,647
counter
High-speed counter
Single-phase single counter
input
Bi-direction (32 bit) (EEPROM
hold)
C235～C245
-2,147,483,648～+2,147,483,647 Counter
Software counter
Single phase：at most 6 channel, 60kHz
Double phase：double frequency：at most 2-3
channels,60KHz
M8198 is 4 times frequency sign of
C251.
Quad frequency：at most 2-3
channels,24kHz
M8199 is 4 times frequency sign
of C253.
Single-phase double counter
input
Bi-direction (32 bit) (EEPROM
hold)
C246～C250
Double –phase double counter
input
Bi-direction (32 bit)(EEPROM
hold)
C251～C255
Name
Contents
Data register(32 bit when using in pair)
General(16bit)
D0～D127
128 points
Special (16 bit)*2
D8000～D8511
512 points
Index (16 bit)
V0～V7,Z0～Z7
16 points
Extended register·extended file register
Extended register(16 bit)*1
R0～R23999
24000points Maintain when power off not
