4. Programming
30 496478
To change: Key-in: Notes Default
Zone nn nn
YY
ab nn = zone number 01 to 16
(Note: for zones 1 to 9 key
a = Zone type, one of:
in “01” to “09”.) 0 = NU (not used) Z01 =FEb
1 = PA (panic alarm) Z02=ERb
2 = FR (fire zone) Z03-Z07=NAb
3 = NA (normal alarm) Z8=PA
4 = 24 (24 hour zone) Z09-Z16=NU
5 = FE (final exit)
6 = ER (entry route)
7 = SA (Shock Analyser)
8 = TC (Technical)
b = Zone attributes, any of:
X1 = C (chime)
X2 = S (soak test)
X3 = D (double knock)
X4 = O(Omit allowed)
X5 = b (armed in part set B)
X7 = Shock Analyser sensitivity (enter a
number in the range 1 (lowest) to 4
(maximum)
Example: Zone 3 is a Normal Alarm, active in Part Set B, that is Omit Allowed.
Type in: 03YY Zone Number
3 Normal Alarm
X5 Active in Part Set B
X4 Omit Allow
Y to store the value of the command.
Engineer Code 20
Y
nnnn nnnn = New engineer code 7890
LS Chime Output 22
Y
n Loudspeaker chime volume
0 = Off ( Keypad only)
1=low, 9=max 5
RedCare reset 23
Y
0 Off Y
1On
Internal Sounder 25
Y
0 LS Timed (Follows external bell) Y
1 Continuous
Sounder Delay on Entry 26
Y
0 Bell Delay off
1 Bell Delay on Y
Exit fault external sounder 27
Y
0 Internal Y
1 Local
Status display 28
Y
0 Status off (180 seconds after setting) Y
1 Status on
PA Response 30
Y
0 Audible Y
1 Silent
