4. System Configurations
497096, Issue 6 Page 77
Programming Partitions
Once you have selected a partitioned system, you can use the following
commands to program each partition:
1. Use Commands 01 to 16 and X17 to X40 to assign each zone to a
partition.
Each zone defaults to Partition A.
Press A to assign zones to Partition A.
Press B to assign zones to Partition B.
Press C to assign zones to Partition C.
Press D to assign zones to Partition D.
(See also "Setting Up A Common Area" on page 79.)
2. Use Command 32 to assign each keypad to a partition as required. By
default all keypads belong to all partitions.
3. Program Exit Mode, Alarm Response and Exit Time for each partition:
Partition A B C D
Exit Mode C39 C62 C72 C76
Alarm Response C47 C63 C73 C77
Exit Time C44 C65 C75 C79
4. Use Commands 81 to 84 to assign bell outputs to each partition as
required.
Option 18 assigns an output to Partition A
Option 19 assigns an output to Partition B
Option 20 assigns an output to Partition C
Option 21 assigns an output to Partition D
5. Make sure that the master user understands how to assign individual
user codes to each partition.
