Copeland C Series User Manual

26
Function 04 Read Input Registers
Address Register name Short description
Medium
description
Long description
Max
value
Min
value
Unit of
Measure
Modbus
Bit pos.
Modbus
Length
Default
Value
101 Concentration Concentration ppm Sensor
concentration in
“units”
Sensor
concentration in
“units”
65535 0 0 16
102 Status_0 No ICM contact No contact
with the sensor
module (ICM)
No contact
with the sensor
module (ICM)
1 0 0 1
102 Status_1 No response from
the sensor
Sensor module
(ICM) signals no
contact with the
sensor
Sensor module
(ICM) signals no
contact with the
sensor
1 0 1 1
102 Status_4 Over range Sensor over range Sensor over range 1 0 4 1
102 Status_5 Under range Sensor under
range
Sensor under
range
1 0 5 1
103 Range Full scale Sensor full scale Sensor full scale 65535 0 ppm 0 16
105 DaysOnline DaysOnline Number of days
online
Number of days
online
65535 0 day 0 16
106 ModbusAddress Modbus address Detector Modbus
address
Detector Modbus
address
247 0 0 16 0
107 SWVer SWVer Firmware version Firmware version 65535 0 0 16
108 MachineCode MachineCode MachineCode MachineCode 65535 0 0 16
113 HWVer HWVer Hardware version Hardware version 39321 0 0 16
114 SensorType Sensor type Sensor cross-
reference table
value
Sensor cross-
reference table
value
999 0 0 16
115 Units Units Sensor
concentration
unit
Sensor
concentration
unit
999 0 0 16
116 AnalogOutputValue Analog output Analog output
value
Analog output
value as a
percentage
100 0 % 0 16
117 Gas Group Gas group listed
in the table
1 R32 mixtures, 2
mixtures, 2 HFC/
HFO, 3 HC, 4 CO2
5 1 0 16
118 DaysSince Service Days since service Days since last
service performed
Days since last
service performed
65535 0 day 0 16
119 MaxDaysOnline Max days online Maximum number
of days online
allowed for the
sensor
Maximum
number of days
online allowed for
the sensor before
replacement is
required
65535 0 day 0 16
120 MaxDaysToService Max days to service Maximum days
until next service
Maximum days
until next service
65535 0 day 0 16 365
5.9 Table of Modbus Variables
Each device connected to the same RS485 bus must have its own address, otherwise there will be conflicts in
transmission/reception that prevent serial communication.
The write registers are password-protected. By entering the password in the appropriate
register, authorization to write the variables will be provided for 15 minutes. There is a specific variable that
indicates whether or not the device is currently locked.
