300 SERIES USER GUIDE
22
Eurocard Mount
All connections to the amplifier are made via the DIN connector.
The Eurocard may be ordered with the same additional options as the MB4 card:
Voltage-Mode operation with IR compensation (-V option)
PWM Inputs (-D option)
Edge Filters (-F option)
Heatsink options available with the Eurocard mounting are the -H, and -HX, for standard
and extended heatsink. The 10HP spacing will accept the -H heatsink, but a wider
spacing is required for the -HX extended heatsink.
DIN Connector Pinouts
C A
+Ref Input !
!!
! 2 !
!!
! -Ref Input
Signal Ground !
!!
! 4 !
!!
! Signal Ground
Tach Input !
!!
! 6 !
!!
! Aux Input
+14V !
!!
! 8 !
!!
! -14V
Logic Ground !
!!
! 10 !
!!
! Current Monitor
/Pos Enable !
!!
! 12 !
!!
! /Neg Enable
/Reset !
!!
! 14 !
!!
! /Enable Viewed from
Logic Ground !
!!
! 16 !
!!
! Status backplane
Power Ground !
!!
! 18 !
!!
! Power Ground wiring-side.
Power Ground !
!!
! 20 !
!!
! Power Ground
Pos Output !
!!
! 22 !
!!
! Pos Output
Pos Output !
!!
! 24 !
!!
! Pos Output
Neg Output !
!!
! 26 !
!!
! Neg Output
Neg Output !
!!
! 28 !
!!
! Neg Output
High Voltage !
!!
! 30 !
!!
! High Voltage
High Voltage !
!!
! 32 !
!!
! High Voltage
Table 16
Note that the power ground, pos/neg outputs, and high voltage signals each share four
pins. These pins should be wired together on the backplane so that the higher currents
carried by these these signals are shared by the pins.
Jumper Settings
1. Basic: Standard voltage to current configuration
2. Voltage Mode: Voltage-in to voltage-out mode.
3. IR Comp Voltage mode with armature resistance compensation
4. PWM 0-100%: PWM signal applied to REF+ input, Direction signal applied to REF- input.
5. PWM 50%: PWM signal applied to REF- input, 50% duty cycle gives 0 output, 0 and 100%
duty cycle give max positive/negative outputs.
JUMPER BASIC VOLTAGE IR PWM PWM Signal
only COMP 0-100% 50%
JP-101
1-2 1-2 2-3 Amp Aux
JP-102
1-2 1-2 2-3 Curr Mon
JP-104
1-2 2-3 PWM type
JP-105
2-3 2-3 2-3 1-2 1-2 Amp Ref+
JP-106
2-3 2-3 2-3 1-2 1-2 Amp Ref-
JP-107
2-3 1-2 1-2 Amp Tach
JP-108
1-2 1-2 1-2 2-3 2-3 Card Ref+
JP-109
1-2 1-2 1-2 2-3 2-3 Card Ref-
Table 17
