300 SERIES USER GUIDE
iv
A Visual Guide to the 300 family:
Basic Amplifier, No Mounting Card, No Heatsink (30x shown)
See p. 5 for connectors & pinouts.
See pp. 7-8 for wiring.
Amplifier with MB4 Mounting Card (30xPMFDV shown)
See p. 18 for connectors & pinouts.
See pp. 9-10 for wiring.
Amplifier on Eurocard Mount with Front Panel (30xER shown)
See p. 21 for connectors & pinouts.
See. pp. 11-12 for wiring.
