300 SERIES USER GUIDE
33
Eurocard Layout
Jumper Pin Numbering
1
2
3
1-2 2-3
PINS
Panel Layout
P1
S1
R21
R18
R19
JP103
JP101
JP102
JP107
JP104
JP106
JP109
P2
R11
R12
JP108
JP105
BALANCE
REF GAIN
CURR LIMIT
FEEDBACK
ARM FB.
NORMAL
RESET
CURR MON.
