300 SERIES USER GUIDE

Appendix

Connector Part Numbers

Here are the Copley Controls Corp.(CCC), and OEM part numbers for the connectors

used with the 300 series amplifiers:

Basic Amplifier 4-pin power/motor connector

CCC No. 57-0073 (Weidmuller BL4.12593.6)

Basic Amplifier 22-pin signal connector (housing only)

CCC No. 57-0074 (Molex 22-01-3227)

MB4 Card: 4 pin power/motor connector

CCC No. 57-0073 (Weidmuller BL4.12593.6)

MB4 Card: 15 pin signal connector (housing only)

CCC No. 47-0006 (Molex 22-01-2157)

Pins for 15, 22 pin signal connector

CCC No. 46-0000 (Molex 08-50-0114, crimp-tool 11-01-0037)

DIN backplane connector for Eurocard mount

CCC No. 57- (Schroff 69001-698)

References

1. Electrocraft Corp., DC Motors, Speed Controls, Servo Systems, ( Electrocraft Corp.,

1980)

2. Benjamin C. Kuo, Automatic Control Systems, (Englewood Cliffs, NJ: Prentice-

Hall, Inc., 1982)

3. Jacob Tal, Motion Control Applications, (Palo Alto, CA: Galil Motion Control,

1989)

4. Richard C. Dorf, Modern Control Systems, (Reading, MA: Addison-Wesley

Publishing Company, 1980)

5. Richard W. Miller, Servomechanisms: Devices & Fundamentals, (Preston, 1977)
