2 Line Unit (LU1)
LED Name
Color States
Online
GREEN
ON when administrative status for Ethernet interface is online.
BLINKING when manually set to forced blinking.
OFF when administrative status for Ethernet interface is
shutdown or Ethernet link is down.
Link/Activity
GREEN
ON when Ethernet link is up.
BLINKING when Ethernet link is up and there is transmit
or receive activity.
OFF when Ethernet link is down or in shutdown state.
2.7 Cabling
Cabling depends on the SFP, SFP+ or CFP2 type on the optical interfaces, see chapter Pluggable
Tr ansceivers in 8600 Smart R o uters Hardware Installation G uide.
2.8 Laser Safety
See more on laser safety in chapter Pluggable Transceivers in 8600 Smart Routers Hardware
Installatio n Guid e .
Laser safety
[IEC60825-1, A1, A2]
[IEC60825-2]
Check that the operational tempera ture range of the SFP
/SFP+/CFP2 module is suitable for
the installation environment. Note that the temperature of the SFP/SFP+/CFP2 case can be
approximately 15 degrees higher than the ambient temp
erature. For more information on the
allowed SFP/SFP+/ CFP2 case temperature range see chapter Pluggable Transceivers in 8600
Smart Routers H ard ware Installation Guide.
2.9 LU1 Cooling
It is important to ensure that adequate cooling is used when an LU1 is installed in a su brack. LU1
has temperature sensors that monitor the unit temperatures during operation. LU1 can endure a
single fan failure but if two or all the fans of one fan mo dule fail, the LU1 located abov e it will go to
power-save mode after 6 minutes.
Thehightemperaturewarningwillberaisedwhenthecardisoperatedinhighambienttemperature.
This occurs at aroun d +45° C/+113° F ambient. Another reason why this warning can be active is if
the air flow is decreased, which can be caused by a dirty air filter in the subrack. There are also
critical temperature limits w hich will cause the cards to go to power-save mode if they are exceeded.
All em pty line unit slots have to be sh ielded with blank cover plates.
