6 Technical Specifications
Management protocols CLI, F TP, SNMP (read), proprietary B MP.
Configuration Change Notifications (CCN).
Other CPU load gauge.
Memory utilization gauge.
NPU usage gauge.
6.2 LU1 Technical Specifications
LU1 Technical Specifications
Dimensions 61 x 335 x 387,5 m m (w x h x d)
2.40x13.18x15.25in(wxhxd)
Weight 4.4 kg/9.7 lbs without Pluggable Transceivers
Power consumption Typical 190 W
Maximum 220W
Switch/routing engine
NPU
Packet buffer size
2GBytes
MaxIPv4entries
440 K
Max number of IPv4 VPN entries
440 K
Interfaces — One 100GBASE-R CFP2 interface
— Twenty four 1000BASE-X/10GBASE—R
SFP/SFP+ interfaces.
See chapter Pluggable Transceivers in 8600 S
mart
Routers Hardware Installation Guide.
Synchronization Synchronous Ethernet support at both ingress and
egress:
— Optical egress signal synchronized to ETSI
SEC or ANSI Stratum 3 (NE clock)
— Optical ingress signal used as reference for
Timing Modules on the CUs
MTU
Max. 9500 byte frames
VLANs Max. 4096
MAC filter Erroneous frames; Short and too long frames;
Flow control and overflow
Loopbacks Line loop
Power supply Nominal -48 V dc
Card LEDs Green, yellow and red
6.3 SU1 Technical Specifications
SU1 Technical Specifications
Dimensions 57 x 151 x 388.45 mm (w xhxd)
2.24 x 5.94 x 1
5.29 in (w x h x d)
Weight 3.2 kg/7.05 lbs without Pluggable Transceivers
Power consumption Typical 100 W
Maximum 120W
8600 Smart Rout ers 76.8670-40128B
