3 Switch Unit (SU1)
LED Name
Color States
Alarm
RED
ON when SU1 itself has a fault.
BLINKING during the following operations:
1) M anually set to forced blinking.
2) If also yellow LED is blinking, the card/NE has reached
shutdown state after "esw-shutdown" command and can be
removed from N E or power can be switched off.
OFF otherwise.
Alarm
YELLOW
ON when online and SU1 detects some non-critical fault.
BLINKING during the following operations:
1) Boot-up sequence.
2) Inventory create.
3) Inventory (backup) restoration.
4) M anually set to forced blinking.
5) If also red LED is blinking, the card/NE has reached
shutdown state after "esw-shutdown" command and can be
removed from N E or power can be switched off.
OFF otherwise.
OnLine
GREEN
ON when SU1 is online (it is “up” meaning successful boot-up
sequence finished and and the switch matrix is switching).
Note that online NE may still contain errors.
BLINKING when manually set to forced blinking.
OFF otherwise.
Power
GREEN
ON when NE power is ON and undervoltage not detected.
BLINKING Power supply failure.
OFF otherwise.
