6 Technical Specifications
LU1
1-port 100GE + 24-port 1/10 Gigabit Ethernet Line Unit LU1
(1x100GBASE–R / 24x10GBASE-R/1000BASE-X, note the
different operating modes as all ports are not usable at the same time)
Timing block: ETSI SEC or ANSI Stratum 3 timing reference,
SyncIn/Out (RJ-48c and SMB connectors), PPS (RJ-45 connector,
point-to-point ITU-T V.11 interface), E1, 2MHz, T1 SF, and T1 ESF
interfaces.
Management interfaces: RS-232 serial (RJ-45 connector) and
Ethernet (RJ-45 connector) ports.
External Alarm In/Out interface (RJ-45 connector).
Runs routing and label distribution protocols via the control
functionality (CU).
Unit optionally protected (redundant) - synchronization management
androutingprotocols.
SU1
Switch unit.
Coriant recommends that two SU1s a re always used.
Packet buffer size
LU1: 2 GBytes
Performance HW-based architecture guarantees forwarding at wire speed both for
IP and MPLS traffic under any condition.
Throughput:
• 130 Gbp/s bidirectional per LU1 with one operational SU1
• 200 Gbp/s bidirectional per LU1 with two operational S U1s
• 780 Gbp/s bidirectional per subrack assuming simple IMIX LU1
with one operational SU1
• 1200 Gbp/s bidirectional per subrack assuming simple IMIX
LU1 with two operational SU1s
2000 VRFs per LU1 and subrack.
440K IPv4 routes or 440K VPN routes with LU1.
16000 PWE3 tunnels per subrack.
8000 VLANs per LU1.
64 Link Aggregation groups.
16000 ACL entries per LU, 2000 AC L lists per subrack.
2000 Virtual Switching Instances (VSI) with LU1.
500 000 MAC address table with LU1.
IPv4 and MPLS routing and
label distribution protocols and
functionality
Static routing, OSPF-TE [RFC3630], IS-IS-TE [RFC378
4],
(MP)-BGP4 [RFC1771] and [RFC2858], LDP [RFC3036],
RSVP-TE [RFC3209].
IPv4 loadbalancing to RSVP-TE LSPs.
Equal Cost Multi Path (ECMP) routing.
Integrated Routing and Bridging.
IPv4 header compression [RFC2507].
L3 VPN technologies IP VPNs based on [RFC4364].
PWE3 functionality Ethernet raw mode PWE3 [RFC4448].
Ethernet tagged mode PWE3 [RFC4448].
Multi-segment pseudowires [RFC6073].
Pseudowire redundancy [draft-ietf-pwe3-redundancy].
VCCV BFD.
VCCV LSP ping.
Drop counters and history records for Layer 2 pseudowire.
8600 Smart Rout ers 76.8670-40128B
8665 Smart Router FP7.0 Reference Manual © 2015 Coriant.
50
