6 Technical Specifications
Switch/routing engine
FPGA
Power supply Nominal -48 V dc
Card LEDs Green, yellow and red
6.4 8665 Smart Router DC48 Power Input Module Technical
Specifications
DC48 Powe r Input Module (PIM) for 866 5 Smart Router Te chnical Specifications
Dimensions 45.75 x 112 x 385.75 mm (w x h x d)
1.80x4.40x15.18in(wxhxd)
Weight 1.4 kg/3.08 lbs
Input specifications -48 Vdc nominal input voltage (-40 ... —60VDC)
85 A input current
3400 W m aximum power (for the whole NE)
Power consumption Typical 35 W
Maximum 62.5 W
Alarms Battery voltage monitoring
6.5 8665 Smart Router Fan Module Technical Specifications
8665 Smart Router Fan Module Technical Specifications
Dimensions 143x59x375mm(wxhxd)
5.62 x 2.32 x 14.76 in (w x h x d)
Weight 2.2 kg/4.85 lbs
Power consumption Typical 50 W
Max. 100 W
single fan failure Less than 72 hoursTime to change fan module
more than one fan failure Within three hours, or at least within one day
Air filter change At least twice a year
6.6 Timing Block Technical Specifications
Technical Specifi
cations of SEC [G.813] and Stratum 3 [GR-1244-CORE]
Frequency accuracy in free-running condition
± 4.6 ppm
Minimum pull-
in range
± 4.6 ppm
Maximum pull-out range
± 20 ppm
Wander in locked mode < 40 ns ( t < 1 s )
Noise transfer Bandwidth is between 1 … 10 Hz when the clock
system
operates in SEC mode and < 0.1 Hz when
it operates in S tratum 3 mode,
phase
gain < 0.1 dB
76.8670-40128B 8600 Smart Rou ters
© 2015 Coriant. 8665 Smart Router FP7.0 Reference Manual
53
