Cormach MEC 5 - MOTO Wheel Type Calibration

Technical Support Manual – 05/2018 Rel. 2.1.3 Page 28
6.3 Machine calibration for the MOTO wheel type
The calibration for MOTO wheel type (motorcycle wheels) is completely separated from CAR/SUV wheel type because in the
calibration for MOTO a specific adaptor for motorcycle wheels is used and this slightly the shaft balancing.
If the calibration for MOTO wheel type has not been done and the user try to spin the wheel for balancing in the MOTO wheel type
mode, the machine will not run and will display an error code ERR 031.
To perform the calibration for the motorcycle wheels proceed as follows:
Description
1 Switch on the machine.
2
Mount the MOTO flange on the shaft.
3
Make sure that the hole on the shaft adaptor and
one of the holes of adaptor itself are in line.
Put the flange for motorcycles in the
vertical
position.
4
Press [F+P3] . The display
will show the message in the picture on the left (this
indicates that we have entered Service mode).
5
Press [P3] . The writing CAL Car will be
displayed on the
display (machine calibration for
passenger car and off-road vehicle wheels).
6
Press [P3] . The writing CAL Mot will be
displayed on the display (machine calibration for
motorbike wheels).
7
Press [P3] to confirm. The message in the
picture will be shown on the display.
8 Lower the wheel guard: the machine will run a spin.
