IntelliCarb Drop-In Ice Cooled Installation Guide
Publication Number: 630460204INS - 8 - © 2003-2017, Cornelius Inc.
DELIVERY INSPECTION AND UNPACKING
Upon delivery inspect the unit for damage or irregularities and immediately report problems to the delivering carrier
and file a claim with that carrier.
Open loose parts packages and inspect parts.
Figure 2.
Make sure all items are present.
Part Name
Dr
op-In
P/N Qty.
Pump &motor assy. 629087457 1
4" legs n/a n/a
Clamps Oetiker n/a
Drain pan drain line 167090002 1
Cold plate drain line 167467072 1
Merchandiser assy. 166167010 1
Transformer 630000601 1
Ftg-3/4 Soc x 3/4 fpt n/a n/a
Ftg-3/4 mptx1" barb n/a n/a
