cal gas 3
Digital output driving high value calibration gas air
actuator
range 1 (optional)
Extended range execution indicating second
mixing chamber is selected for dual range option
stream 1 (Standard)
Indicating process stream 1 selected
stream 2 (optional)
Indicating process stream 2 selected
Stream sw
Status, switching streams
High alarm
High Calorific value
Low alarm
Low Calorific value
Calibrate
Calibration in progress
Validate
Validation in progress
Calibration fault
Calibration fault
Sys fault
Collective alarm
In op
Analyzer is in operation
System Ok
Status box, also displays access level and fault
Explanation inputs
Calibration req
External input to start calibration
Validation assignment
External input to start validation
Calibration gas pressure
Calibration gas pressure regulator (input)
Air pressure
Instrument air pressure regulator (input)
Sample pressure
Sample pressure regulator (input)
Flow alarm A (optional)
This digital input has no function at present
Flow alarm B (optional)
As above
Flow alarm C (optional)
As above
Flow alarm D (optional)
As above
Flow alarm E (optional)
As above
