LATCH: Lower Anchor Install
3029
Before you begin installing the car seat
into your vehicle, did you check:
Remove Lower Anchor Belt
from Storage Attachments
Or if the lower anchor belt was
used Forward-Facing,
remove it from the Forward-
Facing Belt Path so both hooks are
on the same side of the car seat as
shown.
1
2
Your child’s weight and height?
5-40 lb (2.3-18 kg) and
19-40 in. (48-101.6 cm)
Your child’s fi t? See page 6.
Do you need to make adjustments to the
harness strap position or the buckle position?
Locate Rear-Facing Belt Path
Place Car Seat Rear-Facing
in Back Seat
Route Lower Anchor Belt
Thread the hook through the Rear-
Facing Belt Path opening as shown.
The adjuster can be on either side of
the car seat.
The belt goes:
• across the car seat; AND
• under the car seat pad; AND
• in front of the buckle; AND
• out the other Rear-Facing Belt
Path opening.
Do not twist belt.
Finished Lower Anchor
Belt Routing
3
4
LATCH: Lower Anchor Belt Install
