Removing Harness System
47
continued on next page
Only remove the harness system to clean the seat pad.
To remove accessories, see page 2.
Fully Loosen Harness Straps
Turn Car Seat Over
Locate the harness straps’ metal
retainers on the bottom of the shell.
From Back of Car Seat,
Remove Harness Strap
Loops From Splitter Plate
1
2
3
48
Remove Metal Retainers
From Tabs
Using a fl athead screwdriver, gently
lift the metal retainer off of the tab.
Make sure the screwdriver does not
touch the harness strap.
Repeat for the other side.
Push Metal Retainers Up
Through Shell and Pad
As Shown
Repeat for the other side.
Locate Buckle’s Metal Retainer
4
5
6
To Next Page
