continued on next page
LATCH: Lower Anchor Use
16
Vehicle
Seat Bight
LATCH: Lower Anchor Bars
For Use in Rear-Facing Mode
or Forward-Facing Mode
Your vehicle’s features may be considerably different
than those pictured here.
The lower anchors of LATCH (Lower Anchors and Tethers for
CHildren) is a universal system for installing car seats without using
vehicle seat belts.
The LATCH: lower anchor belt can only be used in vehicles that have
the lower anchor bars installed in designated seating positions. Most
vehicles manufactured after September 2002 are equipped with
LATCH: lower anchor bars.
Check your vehicle owner’s manual to see which seating positions
may be equipped with LATCH: lower anchor bars.
Do not use both the lower anchor belt and vehicle belt
at the same time. When used correctly the lower anchor
belt or the vehicle belts are equally safe.
Pull Harness Straps Out of
Shoulder Harness Slots
Attach 2nd Harness Strap
Loops to Splitter Plate As
Shown
The sewn ends of the harness strap
loops must face towards you.
Do not twist the harness strap or the
harness adjustment strap.
Make sure the harness strap loops
are fitted completely on both sides
of the splitter plate.
9
7
Rethread Harness Straps into
Correct Shoulder Harness Slots
For Your Child
8
15
Check your child’s fit often.
To learn how to check harness tightness, see pages 44-46.
Check the harness straps often for any wear or damage.
For Rear-Facing Child Fit,
see page 6.
For Forward-Facing Child Fit,
see page 7.
The harness system must be installed correctly. Do not
use a child restraint with damaged harness straps.
To Next Page
