continued on next page
LATCH: Lower Anchor
+ Tether Install
40
39
1
Remove Lower Anchor Belt
from Storage Location
Or if the lower anchor belt was
used Rear-Facing, remove the belt
from the Rear-Facing Belt Path so
both hooks are on the same side of
the car seat as shown.
Before you begin installing the car seat
into your vehicle, did you check:
Your child’s weight and height?
22-50 lb (10.1-22.6 kg) and
29-43 in. (73.6-110 cm)
Your child’s fi t? See page 7.
Do you need to make adjustments to the
harness strap position or the buckle position?
Route Lower Anchor Belt
Thread the hook through the
Forward-Facing Belt Path opening
as shown.
The adjuster can be on either side of
the car seat.
The belt goes:
• across the car seat; AND
• under the car seat pad; AND
• out the other Forward-Facing
Belt Path opening.
Do not twist belt.
Finished Lower Anchor
Belt Routing
3
Locate Forward-Facing
Belt Path
2
To Next Page
