Cotek SP-3000 - SP-2000 Specification

14
Electrical
Specification
Model No.
Item
SP-2000-112
SP-2000-124
SP-2000-148
Safety & EMC
Safety Standards
Certified UL 458
(UL only for GFCI receptacles)
----
EMC standards
Certified FCC class B
E-mark
----
Dimension(WxHxD)
248mm X 83mm X 443mm
Weight
5.24 KG
Cooling
Temperature & Load Controlled cooling Fan
AC Transfer Function Accessories
TR-40 (optional)
Table 7. SP-2000 for Output 100/110/115/120 VAC Specification.
Note：
 Voltage range：Please refer to Figure 1
 Normal load Condition： Vin =12.5V/25V/50V,
Vo=100/110/115/120 VAC 80% Full load (PF=1.0)
 Operating temperature：Please refer to Figure 2
2-3-8. SP-2000 Specification
Electrical
Specification
Model No.
Item
SP-2000-212
SP-2000-224
SP-2000-248
Input
Characteristics
Voltage
12VDC
24VDC
48VDC
Input Over-Voltage
Protection
16.5 ± 0.3VDC

33 ± 0.5VDC

66 ± 1.0VDC

Input
Under-Voltage
Protection
10.5 ± 0.3VDC
21 ± 0.5VDC
42 ± 1.0VDC
Voltage Range
10.5~16.5 VDC
21~33 VDC
42~66 VDC
No Load Current
<1.8 A @12VDC
<0.9 A @24VDC
<0.5 A @48VDC
Power Saving
Mode
<0.1A @12VDC
<0.05A @24VDC
<0.05A @48VDC
Output
Characteristics
Continuous Output
Power
2000 VA(± 3%)
Maximum output
Power (1Min)
> 2000 VA~2300 VA (100%~115%)
Surge Power
(1Sec)
< 3500 VA
Frequency
50 / 60 Hz ± 0.5% (Dip Switch Selectable)
Output Voltage
200 / 220 / 230 / 240 VAC (± 3%)
(Dip Switch Selectable)
Efficiency max.
89%
89%
90%
