Cotek SP-3000 - SP-4000 Specification

20
Electrical
Specification
Model No.
Item
SP-4000-124
SP-4000-148
Dimension(WxHxD)
255mm X 158mm X 462mm
Weight
10 KG
Cooling
Temperature & Load Controlled cooling Fan
AC Transfer Function Accessories
TR-40 (optional)
Table 11. SP-4000 for Output 100/110/115/120 VAC Specification.
Note：
 Voltage range：Please refer to Figure 1
 Normal load Condition： Vin =25V/50V,
Vo=100/110/115/120 VAC 80% Full load (PF=1.0)
 Operating temperature：Please refer to Figure 2
2-3-12. SP-4000 Specification
Electrical
Specification
Model No.
Item
SP-4000-224
SP-4000-248
Input
Characteristics
Voltage
24VDC
48VDC
Input Over-Voltage
Protection
33 ± 0.5VDC

66 ± 1.0VDC

Input Under-Voltage
Protection
21 ± 0.5VDC
42 ± 1.0VDC
Voltage Range
21~33 VDC
42~66 VDC
No Load Current
<1.9 A @24VDC
<1.0 A @48VDC
Power Saving Mode
<0.2A @24VDC
<0.1A @48VDC
Output
Characteristics
Continuous Output Power
4000 VA(± 3%)
Maximum output Power
(1Min)
> 4000 VA~4600 VA (100%~115%)
Surge Power (1Sec)
< 8000 VA
Frequency
50 / 60 Hz ± 0.5% (Dip Switch Selectable)
Output Voltage
200 / 220 / 230 / 240 VAC (± 3%)
(Dip Switch Selectable)
Efficiency max.
88%
90%
Short-Circuit Protection
1 Sec Shutdown
Output Waveform
Pure Sine Wave (THD < 5%@ Normal Load)

Signal and
Control
Remote Controller Panel
Unit
CR-8 / CR-16 (optional)
LED Indicator
Red / Orange / Green LED
