3. Installation and Maintenance
3-1. AC Output Side (Front Panel) Introduction
Figure 5. SP-700/1000 AC output panel view
Figure 6. SP-1500/2000 AC output panel view
Figure 7. SP-3000/4000 AC output panel view
Model
SP-700
SP-1000
SP-1500
SP-2000
SP-3000
SP-4000
Saving power adjustment
Function switch
Function LED
TRC port (RJ45)
Main switch
AC output socket
AC output terminal
Table 14. SP Series AC output side introduction
