17
Electrical
Specification
Model No.
Item
SP-4000-224
SP-4000-248
Input
Characteristics
Voltage
24VDC
48VDC
Input Over-Voltage
Protection

33 ± 0.5VDC
66 ± 1.0VDC
Input Under-Voltage Protection
21 ± 0.5VDC
42 ± 1.0VDC
Voltage Range
21~33 VDC
42~66 VDC
No Load Current
≦2.0A @24VDC
≦1.0A @48VDC
Power Saving Mode
<0.2A @24VDC
<0.1A @48VDC
Output
Characteristics
Continuous Output Power
4000 VA (± 3%)
Maximum output Power (1Min)
> 4000 VA~4600 VA (100%~115%)
Surge Power (1Sec)
< 8000 VA
Frequency
50 / 60 Hz ± 0.5% (Dip Switch Selectable)
Output Voltage
200 / 220 / 230 / 240 VAC (± 3%)
(Dip Switch Selectable)
Efficiency max.
90%
91%
Short-Circuit Protection
1 Sec Shutdown
Output Waveform

Pure Sine Wave (THD < 3%@ Normal Load)
Signal and Control
Remote Controller Panel Unit
CR-8 / CR-16 (optional)
LED Indicator
Red / Orange / Green LED
Dry Contact Terminal
By a relay
Remote Control Terminal
6-port Green terminal (for inverter ON / OFF)
Protection
Input Protection
Over / Under Voltage, Reverse Polarity
(Internal Fuse)
AC Output Protection
Short-Circuit, Overload
Others
Over / Under Temperature Protection
(by Heat sink Temperature +80℃/-20℃)
Environment
Operating Temp.

-20 ℃~40 ℃
Storage Temp.
-30 ℃~70 ℃
Storage Temp. & Humidity
10 ~95% RH
Safety & EMC
Safety Standards
Certified EN 60950-1
EMC standards
④
Certified EN 55022 class A; EN 55024;
EN 61000-3-2, -3-3;
EN 61000-4-2, 3, 4, 5, 6, 8, 11
E-mark
Certified CISPR 25; ISO 7637-2
Dimension(WxHxD)
255mm X 158mm X 462mm
Weight
10 KG
Cooling
Temperature & Load Controlled cooling Fan
AC Transfer Function Accessories
TR-40 (optional)
Table 12. SP-4000 for Output 100/110/115/120 VAC Specification.
Note：
 Voltage range：Please refer to Figure 3
 Normal load Condition：Vin =25V/50V, Vo=200/220/230/240 VAC 80% load (PF=1.0)
 Operating temperature：Please refer to Figure 4
 Warning：This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
