2-3-2. SP-1000 Specification
Electrical
Specification
Model No.
Item
SP-1000-112
SP-1000-124
SP-1000-148
Input
Characteristics
Voltage
12VDC
24VDC
48VDC
Input Over-Voltage
Protection

16.5 ± 0.3VDC
33 ± 0.5VDC
66 ± 1.0VDC
Input Under-Voltage
Protection
10.5 ± 0.3VDC
21 ± 0.5VDC
42 ± 1.0VDC
Voltage Range
10.5~16.5 VDC
21~33 VDC
42~66 VDC
No Load Current
≦1.5A @12VDC
≦0.8A @24VDC
≦0.5A @48VDC
Power Saving Mode
<0.1A @12VDC
<0.06A @24VDC
<0.05A @48VDC
Output
Characteristics
Continuous Output
Power
1000 VA (± 3%)
Maximum output
Power (1Min)
> 1000 VA~1150 VA (100%~115%)
Surge Power
(Max. 3 Sec)
< 1750 VA
Frequency
50 / 60 Hz ± 0.5% (Dip Switch Selectable)
Output Voltage
100 / 110 / 115 / 120 VAC (± 5%)
(Dip Switch Selectable)
Efficiency max.
92%
93%
93%
Short-Circuit
Protection
1 Sec Shutdown
Output Waveform

Pure Sine Wave (THD < 5%@ Normal Load)
Signal and Control
Remote Controller
Panel Unit
CR-8 / CR-16 (optional)
LED Indicator
Red / Orange / Green LED
Dry Contact Terminal
By a relay
Remote Control
Terminal
6-port Green terminal (for inverter ON / OFF)
Protection
Input Protection
Over / Under Voltage, Reverse Polarity (Internal Fuse)
AC Output Protection
Short-Circuit, Overload
Others
Over / Under Temperature Protection
(by Heat sink Temperature +80℃/-20℃)
Environment
Operating Temp.

-20 ℃~40 ℃
Storage Temp.
-30 ℃~70 ℃
Storage Temp. &
Humidity
10 ~95% RH
Safety & EMC
Safety Standards
Certified UL 458
(UL only for GFCI receptacles)
----
EMC standards
Certified FCC class B
E-mark
----
Dimension(WxHxD)
200mm X 83mm X 372mm
Weight
3.26 KG
Cooling
Temperature & Load Controlled cooling Fan
AC Transfer Function Accessories
TR-40 (optional)
Table 3. SP-1000 for Output 100/110/115/120 VAC Specification.
Note：
 Voltage range：Please refer to Figure 1
 Normal load Condition：Vin =12.5V/25V/50V, Vo=100/110/115/120 VAC 80% load (PF=1.0)
 Operating temperature：Please refer to Figure 2
