3-2. DC Input Side (Rear Panel) Introduction
Figure 12. SP-700/1000
Figure 13. SP-1500/2000
Figure 14. SP-3000/4000
Model
SP-700
SP-1000
SP-1500
SP-2000
SP-3000
SP-4000
①
Remote port (RJ-11)
②
Remote control green terminal
③
Chassis ground
④
DC input connector
Table 27. SP Series DC input side introduction
