COZY CDV155B - Maintenance Instructions

HOW TO PROPERLY ORDER PARTS: In addition to part description and part number, please give model number, serial
number, and type of gas used. This information can be found on the rating plate located in control compartment.
Page 19* Requires 2
MAY 2010 / REV. 05/2010
NAT. CDV255B CDV335B
M
O
DEL NUMBER
S
L.P.
C
DV
2
5
6
B
C
DV
336
B
REF. PART LIST PART LIST
P
A
RT DE
SC
RIPTI
O
NN
O
.N
O
.PRI
C
EN
O
.PRI
C
E
Heat Exchanger Kit, INCLUDES 1 42763 320.00$ 42763 320.00$
Cabinet 3 42755 212.30$ 42755 212.30$
Leg, Right 6 43495 10.80$ 43495 10.80$
Leg, Left 7 43494 10.80$ 43494 10.80$
Front Heat Shield Assembly 9 43481 26.40$ 43481 26.40$
Bottom Heat Shield Assembly 10 43473 11.80$ 43473 11.80$
Vent Cap with Spacer Plat
e
11 & 12 43145 124.00$ 43145 124.00$
Air Intake Tube Assy. (5-9" Wall) 6-3/4"Dia. 15 43200 17.00$ 43200 17.00$
Air Intake Tube Assy. (9-15" Wall) 16 43810 24.30$ 43810 24.30$
Air Intake Tube Assy. (15-24" Wall) 58 43705 26.30$ N/A N/A
Air Intake Tube Gasket 17 70061 3.90$ 70061 3.90$
Vent Exhaust Tube Assy. (5-9" Wall) 4-3/16" dia. 18 43530 20.20$ 43539 14.00$
Vent Exhaust Tube Assy. (9-15" Wall) 19 43820 22.90$ 43828 20.40$
Vent Exhaust Tube Assy. (15-24" Wall) 59 43717 26.10$ N/A N/A
Vent Exhaust Tube Gasket (Requires 4) 20 70062 2.20$ 70062 2.20$
Wall Thimble (5-9" Wall) 21 43552 15.70$ 43552 15.70$
Wall Thimble Extension (5-9" Wall) 22 43236 5.10$ 43236 5.10$
Wall Thimble Extension (9-15" Wall) 23 43835 11.20$ 43835 11.20$
Wall Thimble Extension (15-24" Wall) 60 43730 16.50$ N/A N/A
Wall Thimble Gasket 24 70066 1.80$ 70066 1.80$
Burner Access Doo
r
25 43247 8.80$ 43247 8.80$
Burner Access Door Gasket 26 70060 10.40$ 70060 10.40$
Burne
r
27 70006 58.30$ 70006 58.30$
Manifold 28 70032 20.70$ 70032 20.70$
Manifold Gasket 29 70065 1.40$ 70065 1.40$
Main Burner Orifice (Nat. Gas) 30 70048 3.80$ 70047 3.80$
Main Burner Orifice (L.P. Gas) 30 70039 3.80$ 70049 3.80$
Sight Glass Assembly 31 43252 7.20$ 43252 7.20$
Sight Glass Cove
r
32 43258 1.70$ 43258 1.70$
Sight Glass/Pilot Burner, Gasket 33 70064 1.40$ 70064 1.40$
Pilot Burner Q350A1529 (Nat. Gas) 34 70007 8.80$ 70007 8.80$
Pilot Burner Q350A1537 (L.P. Gas) 34 70008 8.80$ 70008 8.80$
Electrod
e
35 70052 8.70$ 70052 8.70$
Electrode Wir
e
36 70051 3.00$ 70051 3.00$
Piezo Sparke
r
37 80016 6.40$ 80016 6.40$
Piezo Sparker Bracket 38 43263 3.00$ 43263 3.00$
Valve, MV,
Robertshaw
7000MVRLC-Nat. Gas 39 70090 151.10$ 70090 151.10$
Valve, MV,
Robertshaw
7000MVRLC-L.P. Gas 39 70091 160.80$ 70091 160.80$
Valve, MV,
Dexen
6003, Natural Gas 39 84085 151.10$ 84085 151.10$
Valve, MV,
Dexen
6003LP, L.P. Gas 39 84086 160.80$ 84086 160.80$
Pilot Generator, TP75 Millivolt 40 70098 35.90$ 70098 35.90$
Pilot Tubing w/fittings 41 70012 7.30$ 70012 7.30$
Thermostat, Millivolt 42 74592 22.30$ 74592 22.30$
Thermostat Wir
e
N/A 74518 1.50$ 74518 1.50$
Insulated Staples N/A 74209 1.40$ 74209 1.40$
Gasket, Air Pan Top & Bottom (15-1/4x1) 61 *70074 1.40$ *70074 1.40$
Gasket, Air Pan Sides (25x1) 62 *70073 1.40$ *70073 1.40$
90 Degree Elbow 56 70352 11.90$ 70352 11.90$
Vent Terminal Shield N/A 34950 67.60$ 34950 67.60$
Blower Housing w/Motor & Blowe
r
46 70201 118.60$ 70201 118.60$
Junction Box 47 43610 4.70$ 43610 4.70$
Junction Box Cove
r
48 43620 5.70$ 43620 5.70$
Fan Switch 120 degre
e
50 70110 7.00$ 70110 7.00$
Cord Set 51 80202 4.70$ 80202 4.70$
Cover Plat
e
N/A 43078 2.70$ 43078 2.70$
Blower Scree
n
N/A 43635 22.00$ 43635 22.00$
Left Air Intake Baffle N/A 43528 4.10$ 43528 4.10$
Right Air Intake Baffl
e
N/A 43526 3.40$ 43526 3.40$
Wrapper (Ref. # 2), Right and Left Leg (Ref. # 6 & 7), AND
Comb. Air Pan Assembly w/Gaskets (Ref. # 63)
ATTN: CONTRACTORS and SERVICE TECHNICIANS
, we only sell parts through our wholesalers, but the prices
listed above are for your convenience. For prompt parts service, contact the wholesaler from which you purchased your
Cozy heater. NOTE
: Parts & schematic drawings on current models are shown at
www.cozyheaters.com
.
