Step 5
Move the loosely t assemblies to the press making sure proper
alignment stays in tact.
Start applying downward pressure with the ram of the press until
the prongs of the grinding shaft slide into the slots of the retainer.
Very slight movement of the assembly may be needed to ensure
proper alignment.
Do not force the grinding shaft prongs into the retainer with ram
pressure! Start Polycord over the main Mounting Plate studs with
even downward hand pressure until all studs protrude the Polycord
slightly.
Note: Use of a hydraulic press could damage the assembly. A
manual press as shown is recommended.
Recommended type of
manual press.
FLEX HEAD ASSEMBLY INSTRUCTIONS
24/7 Technical Support- Toll Free 1-877-472-8200
35
Concrete Polishing Solutions- G-250XTP Operator’s Manual
