Craftsman C950-52844-1 - Page 35

PART NO. DESCRIPTIONREF NO
Frame
Footnotes
Craftsman 22" Snowthrower C950-52844-1
Screw 1/4-20 x .75 1 302628MA
Washer 2 71067MA
Bracket, Fuel Tank 3 1741771HYP
Cap, Fuel Tank 4 1715917SM
Tank, Fuel 5 1716634SM
Nut, Hex 1/4-20 6 73826MA
Nut, Hex 5/16-18 7 71391MA
HOSE, Fuel Line (Cut to length) 8 7200111YP
Clamp, Fuel Line 9 323387MA
Filter, Fuel Line 10 298090S
Cradle Assembly, Engine 12 1741989HYP
Frame, LH 13 1501872E701MA
Screw, 5/16-18 x 0.63 14 48901MA
Screw, 1/4-20 x 2.00 15 180044MA
Plate, Mounting Support 16 335351MA
Support, Frame 17 1501851MA
Frame, RH 18 1741988AYP
Screw, 5/16-18 x 0.75 19 180077MA
Ring, Foam 20 1740032MA
Clamp, Fuel Line -Screw Type 21 47345MA
Screw, 1/4-20 x .625 22 310169MA
PTS - 3
Not for
Reproduction
