Craftsman C950-52844-1 - Page 37

PART NO. DESCRIPTIONREF NO
Engine Drive System
Footnotes
Craftsman 22" Snowthrower C950-52844-1
Engine, 5HP 4CY B&S 1 09A4130202E1
Cradle Assembly, Engine 2 1741989HYP
Frame, LH 3 1501872E701MA
Antivibration Mount, Engine 4 1502027MA
Bolt, Hex 5/16-18 x 0.865 5 1X216MA
Bolt, Hex 5/16-24 x 1.1125 6 6X118MA
Washer, Flat 7 71071MA
Locknut, Hex Center 5/16-18 8 71391MA
Guide, Belt 9 334079MA
Bolt 10 333594MA
Pad, Brake 11 333970MA
Screw, 1/4-20 x .63 12 579052MA
Idler, Arm Pivot 13 313444MA
Spring 14 313473MA
Nut Hex 1/4-20 15 73826MA
Bolt 16 333594MA
Wire, Brake 17 1501009MA
Spring 18 313471MA
Pin, Cotter 19 121223MA
Arm, Idler 20 1741727YP
Rod, Clutch Linkage 21 313436MA
Pulley, Idler 22 48924MA
Screw, 3/8-16 x 1.62 23 1741500MA
Pulley, Model 9 Engine 24 1501908MA
Bolt, Engine Pulley 25 1501907MA
Washer, Flat 26 71067MA
Screw, 1/4-20 x 2.00 27 180044MA
Pinch Roller 28 1501010MA
Spacer, Idler 29 1741499MA
Nut, Hex 30 590MA
Belt, Drive 31 37x130MA
Bolt, Hex 5/16-18 32 001X81MA
Screw 3/8-16 x 1.00 33 47792MA
Washer, Flat 34 414106MA
Lockwasher, Split 35 71060MA
Nut, 5/16-18 36 71037MA
Instruction Book -- 1739127
PTS - 5
