PART NO. DESCRIPTIONREF NO
Electric Starter
Footnotes
Craftsman 22" Snowthrower C950-52844-1
Screw, No. 8-32 x 3.00 1 311633MA
Washer 2 414106MA
Nut, Keps No. 8 3 271163MA
Lever, Choke 4 791534
Muffler 5-1 699565
Gasket, Muffler 5-2 691880
Bolt, Muffler 5-3 699554
Washer, Split Lock 5-4 71060MA
Nut, Hex 5/16-18 5-5 71037MA
Bolt, Hex 5/16-18 5-6 001X81MA
Cable, Starter 6 6219MA
Grip, Mitten 7 699334
Grommet, Rope 8 57587MA
Washer 9 1502075MA
PTS - 7
Not for
