Craftsman C950-52844-1 - Page 47

PART NO. DESCRIPTIONREF NO
Discharge Chute
Footnotes
Craftsman 22" Snowthrower C950-52844-1
Screw 1/4-14 1 313685MA
Retainer, Chute Ring 2 1502131MA
Ring, Chute 3 1502132MA
Bolt, Carriage 5/16-18 x .75 4 340720MA
Nut 5 71037MA
Neck, Chute 6 1736069YP
Chute, 22" Upper 7 1501918MA
T-Knob 8 1501260MA
Washer 9 71071MA
Lockwasher, Shakeproof 10 019X35MA
Locknut, Hex 5/16-18 11 71391MA
Bolt, Carriage 5/16-18 12 002X97MA
Bolt, Upper Chute 13 1501910MA
Washer 14 71072MA
Nut 15 71038MA
Chute, Lower 16 1501909MA
Gear, 9-Tooth 18 1501067MA
Screw, 1/4-14 x .75 19 313685MA
Nut, Push 20 331532MA
Knob, Sleeve 21 57082MA
Washer 22 71072MA
Crank, Chute Rotation 23 1501870MA
Pin, Hair 25 1501293MA
Yoke Assembly, Adapter 26 1741997YP
Pin, Cotter 27 579493MA
Pin, Universal Joint 28 578060MA
Pin, Clevis 29 578309MA
Housing, Universal 30 578063MA
Rod, Lower Crank 31 1501873MA
Screw 1/4-20 x .75 32 302628MA
Blade, Scraper 33 1501863MA
Locknut, Hex 1/4-20 34 15X143MA
Pin, Cotter 35 71082MA
PTS - 15
