Craftsman C950-52844-1 - Page 49

PART NO. DESCRIPTIONREF NO
Handle Assembly
Footnotes
Craftsman 22" Snowthrower C950-52844-1
Handle, Upper (Foam) 1 1742099YP
Control, Bail 2 1742021HYP
Boot, Clutch Spring 3 308146MA
Cable, Upper Control 4 1502042MA
Bracket, Control Adjust 5 313441MA
Cable, Lower Control 6 313448MA
Spring 7 313471MA
U-Bolt 8 1501877MA
Washer 9 311936MA
Knob, Wing 10 1740436MA
Handle, Lower 11 1741982HYP
Nut 12 73826MA
Washer 13 71067MA
Screw, 1/4-20 x 1.25 14 313674MA
Tool, Clean-out 15 304361MA
Screw 16 414291MA
Clip, Retainer 17 1501672MA
Nut 18 997319MA
Nut 5/16-18 19 71037MA
PTS - 17
