PART NO. DESCRIPTIONREF NO
Top Cover
Footnotes
Craftsman 22" Snowthrower C950-52844-1
Panel, Control 1 1740006MA
Screw 1/4-20 x 1.62 2 1741503MA
Washer 3 71067MA
Nut,1/4-20 4 73826MA
Bushing, Chute Crank 5 1501874MA
Nut, 5/8-32 6 300193MA
Keys & Ring, Starter 7 691959
Bulb, Fuel Primer 8 394281S
Panel, Cover Access 9 1501878MA
Nut, Keps 1/4-20 10 271172MA
Hose, Primer 9.5" 11 335507MA
Switch, Ignition 12 56992MA
Handle, Lower 13 1741982HYP
Screw 1/4-14 x .75 14 1740053MA
J-Nut 1/4-10 15 578109MA
Cover, Bottom 16 1740004MA
Cover, Belt 17 1740005MA
Screw 10-24 x .5 18 1740051MA
Locknut, Hex 10 -24 19 1740052MA
Locknut, Hex 1/4-20 20 1740056MA
Screw 1/4-20 x .63 21 1740425MA
Cover, Top 22 1741758YP
Washer 24 313683MA
Cover, Oil Access 25 1741759YP
Gasket, Chute Ring 26 1501995MA
Push Nut 27 028X85MA
Clamp, Cable 28 583435MA
J-Nut, 1/4-10 x .70 29 1740407MA
Screw, 10-24 x .72 30 1740426MA
Screw, 10-24 x .95 31 1740427MA
PTS - 19
