9 Prior to commissioning the engine
Gearbox
Gearbox
The gearbox is located at the rear of the engine and it
must also be filled with the correct type and quantity
of lubricant.
Craftsman Marine diesel engines are supplied with
gearboxes of several brands and types.
For the ZF-Hurth and Technodrive brands the types
and quantities are specified here below:
Please consult the appropriate instruction manuals in
the case of other gearbox makes and models.
Here it is shown how the gearbox can be filled up with
its lubricant. When the filling is completed, verify with
the dipstick whether the correct level of fluid is
obtained.
ZF Hurth
Type ZF 10: 0,35 liter ATF
Type ZF 12: 1,1 liter ATF
Technodrive
Type TMC40: 0,20 liter SAE 20/30
Type TMC60: 0,80 liter SAE 20/30
(ATF: Automatic Transmission Fluid, type A,
suffix A)
