Craftsman CM2.16 - Overall Dimensions; Dimensions for CM2.12;CM2.16

48 pages

Save Page as PDF

To Next Page

To Previous Page

Fuel return Ø 8 mm

Fuel supply Ø 8 mm

Exhaust

Ø 40 mm

Sea Water Intake Ø 20 mm

17 Overall Dimensions

CM2.12 / CM2.16

44 craftsman marine diesel engines CM2.12 , cm2.16 / cm3.27

Exhaust

Ø 40 mm

Fuel supply

Ø 8mm

Sea Water Intake Ø 20 mm
