8 craftsman marine diesel engines CM2.12 , cm2.16 / cm3.27

Table of Contents

1 Disclaimer2
2 Add Serial Numbers and Owner's Data 23
3 Preface4
- Table of Contents4
- Table of Contents5
5 Standard Scope of Supply6
6 General Maintenance Directives 67
7 Safety 79
- Explanation of Symbols9
8 Product Description10
- Designation of Engine Components10
  - Service Side10
  - Starter Motor Side11
- Identification Tag,Engine Number12
  - Position of Identification Tag12
  - Mitsubishi Engine Serial Number12
9 Prior to Commissioning the Engine 913
- Engine Lubrication Oil13
- Gearbox14
- Cooling Liquid15
- Engine Instrument and Control Panels16
10 Engine Operation18
- Starting18
  - Check First18
  - The Starting Procedure18
- Start / Stop19
11 Maintenance and Inspection20
Recording of Data for Verification20
Every 10 Hours or Daily20
- After the First 50 Hours of Operation20
- After Every 100 Hours of Operation20
- After Every 500 Hours of Operation20
- After Every 1000 Hours of Operation20
Check Level of Engine Lubrication Oil21
- Dipstick21
- Oil Level21
- Topping up the Lubrication Oil21
Cooling Liquid22
- Check-Up of Coolant Level22
- Replace Cooling Liquid22
Cooling Water Strainer23
- Checking of the Cooling Water Strainer23
- Cleaning of the Cooling Water Strainer23
- Check Once Again23
Water Seperator / Fuel Filter24
- Danger25
- The Fuel Filter25
- Draining of the Water Separator25
- Bleeding of the Fuel System25
Engine Lubrication Oil26
- Changing of the Engine Lubrication Oil26
- Fitting the Oil Filter26
- Preparation of the New Oil Filter26
Positioning of the Oil Filter27
- Adding New Oil Filter27
Gearbox Oil28
- Checking of Oil Level in Gearbox28
- Draining the Oil from the Gearbox28
- Adding Oil28
Fuel Filter29
- Remove the Fuel Filter29
- Fit the Fuel Filter29
- Cleaning the Filter of the Fuel Lift Pump29
Mountings,Hose Connections, Fasteners30
- Check the Flexible Engine Mountings30
- Verify the Hose Connections30
- Verify the Fasteners30
- V-Belt31
12 Winter Storage32
- Protective Fuel Mixture32
- Lubrication Oil System32
- Raw Water Cooling System32
- Inner Circuit of the Cooling System33
- Electrical System33
- Filters33
13 Preparations for the New Season34
14 Problems and Solutions36
15 Technical Data40
- Craftsman Marine Engine Model40
16 Lubricants and Cooling Liquids42
- Viscosity42
- Engine Oil42
- Oil Lubrication System42
- Cooling System42
- Lubrication Oil in Gearbox42
- Fuel (Summer Period)43
- Fuel (Winter Period)43
- Cooling Liquid43
- Table of Anti-Freeze Concentration Used for Engine Coolant43
17 Overall Dimensions44
- Cm2.12 / Cm2.1644
- Cm3.2745
- Notes46
