7. Environment
• Operational temperature: -20 to + 85°C.
• Storage temperature: -30 to +85°C.
• Humidity: 5 to 95%. The PCB is tropicalized to be used in humid climate areas. Protection IP20.
• Altitude: 2000m.
• Size: 275x200x26mm.
• Mounting: Can be placed in all positions.
• Weight: 1.5Kg.
• Directive CE:
o Generic emission standard: EN 50081-2, EN 50082-2.
o Generic immunity standard: EN 61000-6-2.
o Low voltage directive: 73/23EEC.
8. Dimensions
10mm
275mm
165mm
25mm
200mm
25mm
nut 5 grounding
Holes
x4
D=5mm
115mm
255mm
