5.6.14 Calibrate Sync
This is a special mode used for calibrating the light to an external sync source, such as the FlashBandit sync box. It is used to
make sure the camera shutter and Vortex8 are synchronised, to prevent the flash-banding eects when shooting on a CMOS
sensor camera or when using frame synchronised eects such as Flash Frames.
SETTING RANGE DESCRIPTION
SYNC PHASE 0-360 Change the phase oset of the camera sync input. Adjust until the flashing light cannot be seen in the camera monitor.
Ensure that you setup a camera sync signal that is connected to the Accessory port. See 7. Camera Sync for
a more detailed process of this setup.
