10. Specifications
10.1 Specs for the Accessory Port Pinout
Connector Type: Weipu Socket 7Pin
Mating Plug: Weipu Plug 7Pin SF1210/P7II
Pin Description
1 Sync/Trigger Input +Ve (5-24V Input, referenced to GND)
2 DMX Data (-Ve)
3 DMX Data (+Ve)
4
5
6 GND, Ground Reference
7 +12V Output, 200mA maximum
