9. Power
9.3 Pinout for DC Power connector on Vortex8
Choose a 4 core cable of >17AWG (1.0mm2) and wire all 4 pins.
For a ready-made battery cable with 3 Pin XLR connector (Pin 1: -ve, Pin 2: +ve) see Creamsource Part number:
CS-PWR-5M-XLR3.
Pin Wire To
E - Ve
1 - Ve
2 + Ve
3 + Ve
Part Number Connector Manufacturer Part Number
CSV-8 Vortex8 Ecomate 4 Pin Female Amphenol C016 20D003 110 10
